| Quantity: | |
|---|---|
DD/DL/DJ or non-standard customization
WKDL
521562
Evaporative air cooler is a suitable for a variety of cold storage cooling equipmet, it has the advantages of compact structure,
light weight, no occupation of the use of cold storage area, high efficiency, the cold storage food rapid cooling, greatly
improving the storage of food freshness.
| Blade material: | Aluminum or stainless steel or Nylon |
| Casing material: | Stainless steel or Galvanized steel |
| Motor voltage: | According customer's requirement |
| Bearing: | NSK or SKF |
| Protection Grade: | IP55 |
| Original: | China brand or International brand |
| Blade material: | Coated steel or Aluminum |
| Grille material: | Coated steel or Stainless steel |
| Advantages: | Lower noise, Large air volume,Saving room space, Energy efficiency Erp2015 |
| Original: | Germany Ziehlabegg or China |
| Material: | Copper |
| Tuber OD: | 5/8'' |
| Inside type: | Inner grooved tube |
| Advantages: | Increase inside heat exchange areas of tube and intensity of refrigerant. At least 15% heat transfer efficiency increased |
High Strength Tube
| Material: | 304 or 316L stainless steel |
| Tube OD: | 5/8'' |
| Test pressure: | 5.0Mpa |
| Expanding pressure: | 40Mpa |
| Advantages: | Running more safty, Better corrosion resistance, Good welding quality |
Features
 | Tube & Fin Types·Φ16mm Copper tube or stainless steel tube. |
 | Optimized Design·Sturctures and covers of Unit Cooler are designed by our 3D software . |
 | Optimized Structure& Casing·Using maintance door, checking and maintance will be easier. ·Other option: Aluminum or stainless steel. |
 | Guarantee of Safe Running·Stainless steel Pipe running pressure to 5.0Mpa, Blasting pressure to 40Mpa. |
 | ·Eddy current testing provide good quality of stainless steel tube. ·TIG welding process of bend is fully automatic which can guarantee high strength and good apperance. ·Float-Coil Tech. which can float tubes in the centre of plate holes. Avoiding direct friction between tubes and plates which may causing leakage of tubes in process of running and transport. |
 | Fan System·Extended air throw streamer,air throw can reach to 70m |
 | Rapid Defrosting System ·Electrical defrosting- stainless steel heating pipe, installed in fan, coil and water pan |
Our evaporative air cooler is widely used in cold storage refrigeration, such asfruit / vegetable / seafood / meat /fish cold storage; walk-in workshop; cold chain logistics; it also can bring fresh cool air to enterprise's workshop, public places, business and entertainment places, such as supermarket, rice factory, sauce factory and so on.
Jiangsu Victory Hot-Cooling Technology is a Manufacture + Technical Design company with over 15 years experience.
Our main products are as below :
Package : Exporting standard wooden box package. Thick wooden box can protect evaporator in good condition during long time transporation on sea. A wooden box can be 100kg ~ 200kg, which bear high pressure.
1.What is your delivery time?
10---40days.
2.What are the payment terms?
30% T/T before production and balance before shipment
3.What is your warranty?
One year for the whole unit.
4.What is the valid time of the quotation?
One month.
5.Can we do our OEM logo?
Yes,we can do OEM logo for you.
6.Can you do our country plug?
Yes,we can do the plug according to your request without extra cost.
Contact: Lucy Zhang
Skpe: lucyzhang228627
wechat / whatsapp: 0086 15961187579
