Manufacturer's direct sales of stainless steel V-shaped dry coolers for corrosion resistance

Availability:

Quantity:



Inquire Add to Basket

Model:
DD/DL/DJ or non-standard customization
Brand:
WKDL
Code:
216510

Product Description

Product Description

Adiabatic dry cooler provide a smart way to take advantage of free cooling when surrounding temperature allows for it. They are made with cross-fin copper tubes or stainless steel tube and corrugated aluminum fins, resulting in a combination of compact dimensions and high capacity.

Dry cooler can be easily integrated with liquid-cooled plate heat exchangers, especially in free cooling systems.

Adiabatic dry coolers were designed to achieve an optimized exchange of thermal energy between air and a refrigerant or fluid. In order for dry cooler to work, the air temperature needs to be cooler than water in the system. To cool the system liquid, hot process liquid flows through the dry cooler tubes. The liquid is then cooled by the relatively cold ambient air that is forced through the coil.

The core of our air heat exchangers is the fin coil, built from a circuit of interconnected tube serpentines and fins to increase the heat exchanging surface.

Advantage of WKDL Adiabatic Dry Cooler

1. Modular designs of dry cooler helps in space optimization

2. High efficient fin to tube heat exchanger

3. Zero water wastage : as it is closed loop operation and now water evaporation

4. Negligible maintenance cost : as water treatment, makeup water and replacement of fills are not required.

5. No periodic cleaning requirement

6. Separates process side from any contamination due to closed loop system

7. Casing made of galvanzied steel, enhanced corrosion resistance.

Detailed Images

Machine Parts

Name: Copper Tube

Tube Dia: 15.88mm

Tube Material: Titanium / Red Copper / Stainless steel / Aluminum / Carbon Steel

Main Features

Name: Fin

Fin Thickness: 0.18 /0.2/0.3/0.5/0.8/1.0mm etc

Fin Material: Red Copper/ Stainless Steel/ Aluminum/ Carbon Steel

Fin Coat: Hydrophilic film and anti-corrosion coat

Fin Pitch: 1/2/3/4mm etc

Machine Parts

Name: Axial Fan

Brand: EBM / ZIEHL-ABEGG / Good China Brand

We have common model in stock. If you need special voltage we can order it for you in 20-30 days.

Main Features

Name: Water tube expanding test

All evaporators will be tested twice before out of factory. One test is leakage test, put the evaporator in pool to inspect if there is a bubble. Another test is water tube expanding with 10-30Mpa pressure, our stainless steel tube can bear 30Mpa pressure.

Application

Dry coolers are used in multiple buildings types and applications throughout the HVAC industry, including the following:

Data centers

Office buildings

Hospitals/medical office buildings

Industrial/process systems

Heat transfer/recuperation

Power generation

Induction cooling

Our Service

Software

* We have heat exchange calculation software which can offer optimal solution.

Stainless steel automatic welding Tech

* Imported from Germany and it offer good appearance and high strength.

Our Company

Jiangsu Victory Hot-Cooling Technology is a Manufacture + Technical Design company with over 15 years experience.

Our main products are as below :

* Heat exchanger coils in all types

* Evaporator & Air Cooler ; Condenser ; Dry Cooler ; Adiabatic cooling tower

* Evaporative condenser / cooling tower

Our heat exchange coil has been exported to USA, Canada, Australia, South Africa etc.

Packing & Delivery

Packaging
Size	As per dry cooler size
Weight	200kg-1000kg
Packaging Details	The normal package is wooden box.If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
